MARKA |
ASUS |
GARANTİ SÜRESİ |
36 |
EAN |
4711081112082 |
İŞLEMCİ |
Intel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Supports Intel® 14 nm CPU |
YONGA SETİ |
Intel® B560 Chipset |
BELLEK |
Memory Channels:2DDR4 (Dual Channel)
Max Memory Size:64GB
DDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)
3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)
2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
* 10th Gen Intel® Core™ i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz. |
DAHİLİ GRAFİK |
1 x D-Sub
1 x HDMI 2.0 |
GENİŞLEME YUVALARI |
Intel® 11th &10th Gen Processors
1 x PCIe 4.0/3.0 x16 slot
– Intel®11th Gen processors support PCIe 4.0 x16 mode
– Intel®10th Gen processors support PCIe 3.0 x16 mode
Intel® B560 Chipset
2 x PCIe 3.0 x1 slots |
SES DESTEĞİ |
Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC*
– Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
– Supports up to 24-Bit/192 kHz playback
Audio Features
– Audio Shielding
– Premium Japanese audio capacitors
– Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. |
LAN |
1 x Intel® I219-V 1Gb Ethernet
ASUS LANGuard |
USB PORTLARI |
Rear USB:Total 6 ports
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB:Total 6 ports
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports |
DEPOLAMA ARAYÜZÜ |
Supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Intel®11th Gen Processors
M.2_1 slot (Key M), type 2242/2260/2280
– Only Intel® 11th Gen processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs
Intel®B560 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)*
6 x SATA 6Gb/s ports |
ARKA GİRİŞ/ÇIKIŞ PORTLARI |
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x D-Sub port
1 x HDMI™ port
1 x Intel® I219-V 1Gb Ethernet
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port |
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI |
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin+12V Power connector
Storage related
2 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Miscellaneous
1 x RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x S/PDIF Out header
1 x Speaker header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin System Panel header |
İŞLETİM SİSTEMİ DESTEĞİ |
Windows 10 64bit |
FORM FAKTÖRÜ |
microATX
9.6 inch x 8.3 inch(24.4cm x 21.1cm) |
BIOS |
128 Mb Flash ROM, UEFI AMI BIOS |
